Xenon Accelerated Tester / Xenon weather test machine
Application:
Xenon Accelerated Tester / Xenon weather test machine is a comprehensive climate testing machine, it can do climatic aging test, and also can do fading acceleration test under color effect or color changed. The test range including: dying and finishing, printing, leather, plastic, plyglass, painting, textile, printing ink, rubber and also the industry relative color. Light fastness and fade grade can be known in short time. Those materials exposed at simulated sunlight to evaluated the material’s light fastness performance. To simulate and strengthen the test according to light energy, temperature, rain fall or condensation, humidity, .etc these main climate factors. Adopt simulated sunlight spectrum’s Xenon arc light to create destructive waves under different environment. It can be used for choosing new materials, improving existing materials, or assessment of durability change after material composed.
Xenon Accelerated Tester technical parameters:
| Model | XL - 1000 |
| Internal Dimension WxHxD (mm) | 1000x1000x1000 |
| External Dimension WxHxD (mm) | 1550x2150x1550 |
| Tube Using Life (H) | 1500 |
| Tube Power | 1KW/6KW |
| Illumination Intensity | 340nm 0.35~0.6w/m2 | 420nm 0.8~3.5w/m2 | 300~400nm 48~60w/m2 | 300~800nm 520~800w/m2 | 300~1000nm 575~1000w/m2 | Full spectrum 1200±200w/m2 |
| Lighting Filter Type | Inner filter | Borosilicate | Infrared adsorbing | Borosilicate | Infrared adsorbing | Quartz |
| Outer filter | Borosilicate | Quartz | Soda lime | Infrared adsorbing | Quartz |
| Simulated Test Status | | Test samples; Explore under sunlight | Test samples; Explore under sunlight(Below 300~1000nm) | Test samples: Explore under sunlight through glass window | Test samples: Explore under sunlight through glass window(Below 300~1000nm) | Test samples: Explore under outer space |
| Cooling System | Water cooled or wind cooled |
| Temperature Control Range of the Test Cabinet | Black panel temperature : BPT 40~120℃(±3℃) |
| Black standard temperature :BST 38~120℃(±3℃) |
| Humidity Control Range of the Test Cabinet | Humidity when lighting: 20%R.H.~75%R.H. (± 5%R.H.) |
| Humidity when dark: 60%R.H.~95%R.H. (± 5%R.H.) |
| Rotating Speed of the Samples Holder(RPM) | 1~5 adjustable |
| Diameter of Sample Shelf(mm) | 500±50 |
| Sunlight Exposure Cycle | 0.01~999 hours 59mins |
| Raining Period/ Time | Raining Period:1~240mins,discontinuous-type, adjustable |
| Raining Time:1~9999mins, adjustable, water spray pressure 70~130Kpa |
| Spray water flow(L/min) | 1~2.4 |
| Explore Area(cm2) | 7500 |
| Power | AC 380 V(±10%),50/60HZ ,3∮ 5 Lines |
Xenon Accelerated Tester / Xenon weather test machine features:
1. Advanced design technology and concept,
2. Excellent technology of producing and outstanding system of quality management,
3. Xenon lamp tester can be the most realistic simulated solar spectrum, including ultraviolet,
visible and infrared.
4. Be tested in the range of the full spectrum, necessary for most textile sun and color fastness test.
5. To determine the color fastness and aging to sunlight, weather resistance, etc.
Short introduction about ASLi factory:
We are a long history testing equipment manufacturer, in the past 28 years, we devoted to simulation environmental testing equipment and Mechannical vibration and shock testing machine. Xenon Accelerated Tester / Xenon weather test machine is our star products , and we had obtained the CE certification for this machine .
Package: PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.
Customer Visit ASLI Company:
If you want to learn more knowledge, welcome to contact us at any time.
