High precision Temperature Humidity & Vibration combined test chamber/ three integrated Climatic chamber

Name: High precision Temperature Humidity amp Vibration combined test chamber three integrated Climatic chamber
Brand: ASLi
Price: 1 USD

China High precision Temperature Humidity & Vibration combined test chamber/ three integrated Climatic chamber wholesale

Brand Name : ASLi

Model Number : THV-408(A~F)

Certification : CE ,ISO ,SGS

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, Western Union

Supply Ability : 50 sets per month

Delivery Time : 25~80 workdays

Packaging Details : 1set packed in plywood case to meet long transporation requirements .

Temperature Range : -40ºC to150ºC

Control Accuracy of temperature : ±0.5ºC

Control Accuracy of humidity : ±2.5% R.H.

Power : 380V 50/60Hz

Internal Dimension : W600xH500xD500mm

External Dimension : W1000xH1700xD1900mm

Contact Now

High precision Temperature Humidity & Vibration combined testchamber/ three integrated Climatic chamber

Certificate of these the machine:

China official 3rd party calibration report
CE certiification

Vibration Comprehensive Test Chamber Video for Auto parts:

Model	THV-408(A~F)	THV-1000(A~F)	THV-1500(A~F)
Internal Dimension WxHxD(mm)	600x850x800	1000x1000x1000	1500x1500x1500
External dimension WxHxD (mm)	850x1950x2100	1300x2200x2400	1800x2400x3000
Temperature Range	Low temperature: (A:25ºC; B:0ºC; C:-20ºC; D: -40ºC; E: -60ºC; F:-70ºC) High temperature:100ºC(150ºC)
Humidity Range	20%~98%R.H.(10%-98% R.H. / 5%-98% R.H. is a special optional condition, need Dehumidifier)
Indication Resolution / Distribution uniformity of temperature and humidity	0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H.
Control Accuracy of temperature and humidity	±0.5ºC; ±2.5% R.H.
Temperature Rising / Falling Velocity	Temperature rising approx. 0.1~3.0ºC/min ; temperature falling approx. 0.1~1.5ºC/min; (Falling velocity Min.1.5ºC/min is optional)
Internal and External Material	Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel or see cold-rolled steel with paint coated.
Insulation Material	Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials
Cooling System	Wind cooling or water cooling; single segment compressor for -40ºC, double segment compressor for -70ºC
Protection Devices	Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection
Optional Accessories	Inner door with operation hole(Optional) , Recorder(optional), Water Purifier, Dehumidifier
Vibration Test Equipment	Choose proper vibration test bench according to customer's test condition, the technical parameters please take Electrodynamics Type Vibration Tester's parameters in this catalog for reference
Power	AC380V 3∮ 5 Lines, 50/60HZ

Heated humidification system:
1.Adopt U-TYPE SUS#304ss Electric heat pipe heater
2.Humidify barrel made of SUS#304ss,with observation glass and electromagnetic valve of
water level
3.Idepently heat,wet humidify,dehumidify system. 4.With auto heating,wetting and demist function,with observation glass and imported tube. 4.Humidification water recycling, automatic filling water system,25L built in draw-out type
water tank .

Saftey device:
1.With no-fuse protection switch
2.Over-heat protection
3.Ceramics E-16 fuse
4.high low temperature protection switch for compressor
5.over heat swith for compressor
6.Water shortage alarm, stop machine for long time water shortage protection.

High precision Temperature Humidity & Vibration combined test chamber/ three integrated Climatic chamber

For the package:
1. PP film first
2. Vacuum package
3. PP film again
4. 10mm thickness PU foam to avoid collision
5. stronged plywood case
6. Standard ASLI CASE MARK

Welcome our new and regular customers visit our factory High precision Temperature Humidity & Vibration combined testchamber/ three integrated Climatic chamber, and any inquiries please feel free to contact us !
